Product Details:

4 Colors 2100MM CI Non Woven Fabric Flexographic Printing Machine

XHCI-E-42100mm is a four-color satellite flexographic printing machine for non woven fabric and lazy rag disposable kitchen rags.It is suitable for multi-color continuous exquisite printing of ultra-wide and large roll diameter non-woven materials such as spunlace nonwoven fabrics and spunbonded nonwoven fabrics.It adopts satellite type central large cylinder structure, overprinting accuracy can reach ±0.15mm, environmentally friendly ink printing.

Customized CI Flexo Printing Machine for Nonwoven Fabric 2100mm, 4 colors
1) Max width of material: 2100mm;
2) Manual Color register at ±0.15mm;
3) Max Mechanical Printing Speed 150m/min;
4) Max Roll Diameter:1200mm
5) Pneumatic Auto Loading and Disloading;
6) Video Inspection System







Printing Sample



PRODUCT SPECIFICATIONS
Main technical parameters:
★ Substrate: Nonwoven fabric(30gsm—120gsm)
★ Material Roll Dia: Φmax1200mm
★ Rewinding Dia: Φmax1200mm
★ Printing Colors: 4 Color(only one side printing)
★ Material Width:600--2100 mm
★ Printing Width:550---2050mm
★ Printing lengh: 350---700mm
★ Printing Gear Pitch: 5mm
★ Color Register: ±0.15mm
★ Paper Core Dia:Φ76 mm air shaft
★ Ink: water based; alchol based;
★ Plate Thickness:1.7mm or 2.28mm (depends on customer)
★ Adhesive Tape:0.38mm(depends on customer)
★ Air Consumption: 0.8Mpa 0.25m³/min
★ Total Machine Power:approx 69kw( 380 V AC3 Phase 50HZ)The actual power used is 75% of the total power
★ Mechncail Printing Speed: 150m/min
★ Max Printing Speed: 120m/min(depended on differnt materials, printing pattern and inks such printing process)
★ Color Register: Manual
★ Dimension: 8500×3920×3250mm(L×W×H)
